GrayLib::cProtocolStream Class Reference

#include <cProtocol.h>

Inheritance diagram for GrayLib::cProtocolStream:

Public Member Functions
	cProtocolStream (IProtocolFactory *pProtocolFactory, IUnkObject *pServerConnection, cStreamInput *pStreamInp, cStreamOutput *pStreamOut)
virtual	~cProtocolStream ()
HASHCODE_t	get_HashCode () const noexcept
	STDMETHOD_ (HASHCODE_t, get_HashCodeX)() const noexcept override
	STDMETHOD_ (cString, get_Name)() const override
	STDMETHOD_ (cStringA, get_SymName)() const override
bool	isConnected () const
cStreamInput *	get_StreamInp () const
cStreamOutput *	get_StreamOut () const
virtual size_t	get_ProtocolMaxMessageSize () const
virtual HRESULT	DisposeThis ()
virtual HRESULT	OnTickStream ()
virtual HRESULT	ProcessStreamPacket ()

Public Attributes
IProtocolFactory *const	m_pProtocolFactory
	What IProtocolFactory produced this? More...
IUnkObject *const	m_pServerConnection
	the cNetServerConnection or other top level parent for this protocol. More...
HASHCODE_t const	m_nHashCode
	the m_pClient->get_HashCode() id for this client connection/stream. More...

Protected Attributes
cStreamInput *	m_pStreamInp
	for use with ProcessStreamPacket() More...
cStreamOutput *	m_pStreamOut
	TX responses back to the remote client go here. (e.g. cNetServerConnection->cNetStream) More...
cString	m_sName
	a user readable name. Usually the IP address or reverse DNS lookup. can be upgraded as lookup or login becomes avail. m_pClient->get_Name() More...

Detailed Description

Base class for any server side connection to a client talking a protocol. (Used by cNetServer) e.g. base for cHttpProtocolStream, cSecureServerStream, cSSLServerStream, cXProtocolServerStream, cUnitTestTelnetStream might be the base for CClient type class.

Note

This isolates the protocol/client from cNetSocket. Intentionally separate from all CNet* classes. IUnknown so we may use smart pointer but may also be cXObject based.

Constructor & Destructor Documentation

cProtocolStream()

GrayLib::cProtocolStream::cProtocolStream	(	IProtocolFactory *	pProtocolFactory,
		IUnkObject *	pServerConnection,
		cStreamInput *	pStreamInp,
		cStreamOutput *	pStreamOut
	)

called by cNetServer after the cProtocolStream is created successfully.

• pClient = cNetServerConnection
• sName = usually the IP address of the connection.

~cProtocolStream()

GrayLib::cProtocolStream::~cProtocolStream ( )

virtual

Member Function Documentation

DisposeThis()

virtual HRESULT GrayLib::cProtocolStream::DisposeThis ( void  )

inlinevirtual

Kill the connection from my side. or was remotely closed. so clean up gracefully in cNetServer.

Reimplemented in GrayFTP::cClientFTP, GrayLib::cXProtocolServerStream, GrayLib::cSecureServerStream, and GrayFTP::cClientFTPData.

get_HashCode()

HASHCODE_t GrayLib::cProtocolStream::get_HashCode ( ) const

inlinenoexcept

from m_nHashCode( pClient->get_HashCodeX() )

get_ProtocolMaxMessageSize()

size_t GrayLib::cProtocolStream::get_ProtocolMaxMessageSize ( ) const

virtual

I must be able to hold one full message for processing.

get_StreamInp()

cStreamInput* GrayLib::cProtocolStream::get_StreamInp ( ) const

inline

get_StreamOut()

cStreamOutput* GrayLib::cProtocolStream::get_StreamOut ( ) const

inline

isConnected()

bool GrayLib::cProtocolStream::isConnected ( ) const

inline

OnTickStream()

virtual HRESULT GrayLib::cProtocolStream::OnTickStream ( )

inlinevirtual

Allow the protocol to do stuff on some time tick (not data driven). such as timeout if i don't get any data.

Reimplemented in GrayLib::cXProtocolServerStream, and GrayFTP::cClientFTPData.

ProcessStreamPacket()

virtual HRESULT GrayLib::cProtocolStream::ProcessStreamPacket ( )

inlinevirtual

Incoming m_pStreamInp data handled here. Override this to implement the protocol. Only called if there is new data. I may have to queue up data if incomplete atomic message.

Returns

<0 = error. HRESULT_WIN32_C(ERROR_IO_INCOMPLETE) = not complete message. Caller is responsible to Seek back m_pStreamInp using cStreamTransaction S_OK = processed a single message. commit read.

Reimplemented in GrayLib::cXProtocolServerStream, GrayLib::cSSLServerStream, GrayLib::cSecureServerStream, GrayLib::cHttpProtocolStreamBase, GrayLib::cUnitTestTelnetStream, GrayFTP::cClientFTPData, and GrayFTP::cClientFTP.

STDMETHOD_() [1/3]

GrayLib::cProtocolStream::STDMETHOD_ ( cString  , get_Name    ) const

inlineoverride

for IUnkObject user readable name. from m_sName( pClient->get_Name() )

STDMETHOD_() [2/3]

GrayLib::cProtocolStream::STDMETHOD_ ( cStringA  , get_SymName    ) const

inlineoverride

Give the stream a unique id.

STDMETHOD_() [3/3]

GrayLib::cProtocolStream::STDMETHOD_ ( HASHCODE_t  , get_HashCodeX    ) const

inlineoverridenoexcept

for IUnkObject virtualized version of get_HashCode. from m_nHashCode( pClient->get_HashCodeX() )

Member Data Documentation

m_nHashCode

HASHCODE_t const GrayLib::cProtocolStream::m_nHashCode

the m_pClient->get_HashCode() id for this client connection/stream.

m_pProtocolFactory

IProtocolFactory* const GrayLib::cProtocolStream::m_pProtocolFactory

What IProtocolFactory produced this?

m_pServerConnection

IUnkObject* const GrayLib::cProtocolStream::m_pServerConnection

the cNetServerConnection or other top level parent for this protocol.

m_pStreamInp

cStreamInput* GrayLib::cProtocolStream::m_pStreamInp

protected

for use with ProcessStreamPacket()

m_pStreamOut

cStreamOutput* GrayLib::cProtocolStream::m_pStreamOut

protected

TX responses back to the remote client go here. (e.g. cNetServerConnection->cNetStream)

m_sName

cString GrayLib::cProtocolStream::m_sName

protected

a user readable name. Usually the IP address or reverse DNS lookup. can be upgraded as lookup or login becomes avail. m_pClient->get_Name()

---

The documentation for this class was generated from the following files:

• c:/Dennis/Source/Gray/GrayLib/include/Net/cProtocol.h
• c:/Dennis/Source/Gray/GrayLib/src/Net/cProtocol.cpp
